Description
GSC Power Division Beehive Valve Springs & Titanium Retainers
Fitment: All Audi RS3 (8V / 8Y) & TTRS (8S) DAZA / DNWA Engines
GSC 5096
The GSC Power-Division Beehive Valve Spring Kit with Ti Retainer for the 2017+ Audi RS3 & TTRS DAZA Includes 20 Titanium Retainers and 20 Beehive Valve Springs and 10 Exhaust Seats (Intake retains factory Hat Seal). Our beehive spring utilizes advanced material heat treatment methods for superior load loss capabilities. These springs have the highest level of spring load retention while still maintaining good fatigue throughout the life of the spring. Beehive springs allow for the use of a smaller, lighter retainer allowing for higher RPM and more valve control.
The Audi RS3 beehive valve spring kit is specifically designed for high boost and high RPM applications.
| GSC5096 Beehive Valve Spring Kit with Ti Retainer for 2017+ Audi RS3 DAZA |
|||||
| Setup | Coil Bind (in) | Install Height (in) | Seat Pressure (lbs) | Open Pressure, 11.0mm Lift | Maximum Valve Lift (in/mm) |
| Beehive | 0.900 | 1.418 | 100 | 221lbs @ 0.985″ | 0.472″/12mm |
