Description
Xona Rotor XRE 6569S X4C Ball Bearing ( 950R Turbocharger )
Component Details
– Compressor wheel – 64.9mm Inducer / 84.4mm Exducer
– Over 100lb/min Flow
– Turbine Outlet – 69mm
– 700-1000HP Applications.
– Variable preload angular contact bearings.
– Twin gas ring seals at the compressor and turbine.
– High strength, lightweight stainless steel center housing.
– Full hydraulic damping of the rotating assembly.
– Integrated oil contaminate filter.
– M62 race material allows higher temperature operation.
– Metallic bearing cages.
– 9293 + 006878 / XRE6569S – .63 A/R – V Band In / Out
– 9293 + 006879 / XRE6569S – .82 A/R – V Band In / Out
– 9293 + 006880 / XRE6569S – 1.03 A/R – V Band In / Out
– 9293 – No Turbine Housing
Product Information
The revolutionary UHF™ Aero XR69S turbine delivers the greatest overall flow possible while simultaneously reducing inertia more than 30%, giving the fastest response we have ever observed at this power level.
